The liquid crystal display module and the liquid crystal module refer to components for assembling a liquid crystal display device, a connecting member, a peripheral circuit for controlling and driving, a PCB circuit board, a backlight, and a structural member.
The technical specifications of the liquid crystal display module (LCM) currently available from Xin Hongtai are as follows:
The number of dot matrix is: 122*32, 128*64, 160*32, 256*32, 192*64, 240*64, 160*128, 240*128, 256*128, 320*240, 640*200, etc. Product
Working temperature: normal temperature 0 ~ +50 ° C, wide temperature -20 ~ +70 ° C, ultra wide temperature -30 ~ + 80 ° C;
Interface type: 3-wire or 4-wire SPI serial port, 8-bit or 16-bit MCU parallel port, I2C, RS232 or RS485, USB interface;
Display mode: black on white, black on yellow and green, black on blue, white on blue, white on black, custom silk screen, etc.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Point spacing mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1.7 inch 128 x 64 Graphic LCD | 12864 Graphic LCD | FSTN + Red Green Blue Backlight | Transmissive Polarizer HTM12864C01A-35S-A3P | Graphic LCD Module | 128x64 |
|
52.0x44.2x6.4 | 36.0x23.5 | 33.25x20.45 | 0.38x0.32 | 6H | R/G/B | 12PIN | SPI | Anti-static ESD 8KV | -20~80℃ | +3.3V | ST7567 | |
| 1.7" 128x64 Graphic LCD Block | 128 x 64 Graphic LCD | STN + Yellow-Green Backlight | 3.3V HTM12864C01A-11Y-A3P | Graphic LCD Module | 128x64 |
|
52.0x44.2x6.4 | 36.0x23.5 | 33.25x20.45 | 0.38x0.32 | 6H | YG | 12PIN | SPI | Anti-static ESD 8KV | -20~80℃ | +3.3V | ST7567 | |
| 1.7" Graphic LCD | 128 x 64 Graphic LCD | STN + Transflective Polarizer | Blue on Gray HTM12864C01A-11W-A3P | Graphic LCD Module | 128x64 |
|
52.0x44.2x6 | 52.0x44.2x6 | 33.25x20.45 | 0.38x0.32 | 6H | -20~80℃ | 12PIN | SPI | Anti-static ESD 8KV | -20~80℃ | +3.3V | ST7567 | |
| 1.7" 128 x 64 Graphic LCD | DFSTN negative display | Transflective polarizer | White text on black background HTM12864C01A-41W-A3P | Graphic LCD Module | 128x64 |
|
52.0x44.2x6.4 | 36.0x23.5 | 33.25x20.45 | 0.38x0.32 | 6H | white | 12PIN | SPI | Anti-static ESD 8KV | -20~80℃ | +3.3V | ST7567 | |
| 1.7 inch Graphic LCD128x64 LCD|Graphic module display|STN negative display|Blue background with white characters HTM12864C01A-25W-A3P | Graphic LCD Module | 128x64 |
|
52.0x44.2x6.4 | 36.0x23.5 | 33.25x20.45 | 33.25x20.45 | 6H | white | 12PIN | SPI | Anti-static ESD 8KV | -20~80℃ | +3.3V | ST7567 | |
| 1.7 inch LCD 128x64 Graphic LCD Display | Graphic Module Display, STN + Yellow-Green Backlight HTM12864C01A-01Y-A3P | Graphic LCD Module | 128x64 |
|
52.0x44.2x6.4 | 36.0x23.5 | 33.25x20.45 | 0.38x0.32 | 6H | YG | 12PIN | SPI | Anti-static ESD 8KV | -20~80℃ | +3.3V | ST7567 | |
| 2.0 inch 128x64 LCD Graphic LCD Module | FSTN+Transmissive Polarizer | Red, Green and Blue Backlight HTM12864T01A-35S-A3P | Graphic LCD Module | 128X64 |
|
58.0x51.2x5.2 | 45.2x27.0 | 40.92x24.28 | 6H | R/G/B | 12PIN | SPI | Anti-static ESD 8KV | -30~80℃ | +3.3V | ST7567 | ||
| 2.0 inch 128x64 LCD Graphic LCD Module|128X64 Graphic Dot Matrix Module|Yellow-green Backlight HTM12864T01A-11Y-A3P | Graphic LCD Module | 128x64 |
|
58.0x51.2x5.2 | 45.2x27.0 | 40.92x24.28 | 6H | YG | 12PIN | SPI | Anti-static ESD 8KV | -30~80℃ | +3.3V | ST7567 | ||
| 2-inch LCD Graphic Display Module | 128 X 64 Graphic Dot Matrix Module | STN Positive Display | SPI Interface HTM12864T01A-11W-A3P | Graphic LCD Module | 128x64 |
|
40.92x24.28 | 45.2x27.0 | 45.2x27.0 | 6H | white | 12PIN | SPI | Anti-static ESD 8KV | -30~80℃ | +3.3V | ST7567 | ||
| 2 inch 3.3V 128 x 64 LCD graphic display module | DFSTN negative display | black background white text | SPI | ST7567 controller HTM12864T01A-41W-A3P | Graphic LCD Module | 128x64 |
|
58.0x51.2x5.2 | 45.2x27.0 | 40.92x24.28 | 6H | white | 12PIN | SPI | Anti-static ESD 8KV | -30~80℃ | +3.3V | ST7567 |
