The liquid crystal display module and the liquid crystal module refer to components for assembling a liquid crystal display device, a connecting member, a peripheral circuit for controlling and driving, a PCB circuit board, a backlight, and a structural member.
The technical specifications of the liquid crystal display module (LCM) currently available from Xin Hongtai are as follows:
The number of dot matrix is: 122*32, 128*64, 160*32, 256*32, 192*64, 240*64, 160*128, 240*128, 256*128, 320*240, 640*200, etc. Product
Working temperature: normal temperature 0 ~ +50 ° C, wide temperature -20 ~ +70 ° C, ultra wide temperature -30 ~ + 80 ° C;
Interface type: 3-wire or 4-wire SPI serial port, 8-bit or 16-bit MCU parallel port, I2C, RS232 or RS485, USB interface;
Display mode: black on white, black on yellow and green, black on blue, white on blue, white on black, custom silk screen, etc.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Point spacing mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3.4-inch 192x64 Graphic LCD Display Module/Red, Green and Blue Backlight/MCU/KS0108+KS0107/Arduino HTM19264C-35S-N5P | Graphic LCD Module | 192x64 |
|
100.0x60.0x8.2 | 82.0x31.0 | 98.27x79.16 | 0.41x0.41 | 6H | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108+KS0107 | ||
| 3.4 inch 192x64 Graphic LCD Display Module | 5.0V | Yellow-green Backlight | MCU | KS0108+KS0107 | Arduino HTM19264C-11Y-N5P | Graphic LCD Module | 192x64 |
|
100.0x60.0x8.2 | 82.0x31.0 | 98.27x79.16 | 0.41x0.41 | 6H | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108+KS0107 | |||
| 3.4-inch 192x64 Graphic LCD Display Module | 5.0V | Gray Background with Blue Characters | MCU | KS0108+KS0107 | Arduino HTM19264C-11W-N5P | Graphic LCD Module | 192x64 |
|
100.0x60.0x8.2 | 82.0x31.0 | 98.27x79.16 | 0.41x0.41 | 6H | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108+KS0107 | |||
| 3.4 inch 192x64 Graphic LCD Display Module/Black Background White Characters/MCU/KS0108+KS0107/Arduino HTM19264C-41W-N5P | Graphic LCD Module | 192x64 |
|
100.0x60.0x8.2 | 82.0x31.0 | 98.27x79.16 | 0.41x0.41 | 6H | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108+KS0107 | ||
| 3.4-inch 192x64 Graphic LCD Display Module | 5.0V | Yellow-green Background Display | MCU | KS0108+KS0107 HTM19264C-31W-N5P | Graphic LCD Module | 192x64 |
|
100.0x60.0x8.2 | 82.0x31.0 | 98.27x79.16 | 0.41x0.41 | 6H | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108 | |||
| 3.4-inch 192x64 Graphic LCD Display Module | 5.0V | Yellow-green Background Display | MCU | KS0108+KS0107 HTM19264C-01Y-N5P | Graphic LCD Module | 192x64 |
|
100.0x60.0x8.2 | 82.0x31.0 | 98.27x79.16 | 0.41x0.41 | 6H | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108+KS0107 | ||
| 3.4 inch 192x64 Graphic LCD Display Module | 5.0V | Yellow-green Background Display | MCU | KS0108+KS0107 HTM19264C-01Y-N5P | Graphic LCD Module | 192x64 |
|
100.0x60.0x8.2 | 82.0x31.0 | 98.27x79.16 | 0.41x0.41 | 6H | 0.41x0.41 | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108+KS0107 | ||
| 4.36 inch 192x64 Graphic LCD Display Module | RGB Red, Green and Blue Backlight | Arduino | MCU | AIP31108 HTM19264B-35S-N5P | Graphic LCD Module | 192x64 |
|
120.2x62.0x10.0 | 103.92x38.94 | 97.846x32.462 | 0.508x0.508 | 6H | 21PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | AIP31108 | ||
| 4.36 inch 192x64 Graphic LCD Display Module | STN+Display | Yellow-green Backlight | Arduino | MCU | AIP31108 HTM192645B-11Y-N5P | Graphic LCD Module | 192x64 |
|
120.2x62.0x10.0 | 103.92x38.94 | 97.846x32.462 | 0.508x0.508 | 6H | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | AIP31108 | |||
| 4.36 inch 192x64 Graphic Display Module | STN Positive Display | Gray Background Blue Text | Arduino | MCU | AIP31108 HTM19264B-11W-N5P | Graphic LCD Module | 192x64 |
|
120.2x62.0x10.0 | 103.92x38.94 | 97.846x32.462 | 0.508x0.508 | 6H | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | AIP31108 |
