Location:Home  >  Product center  >  TFT display screen  >  An on-board & Special TFT Module  >  1.3寸方形TFT/全視角/方屏240*240分辨率/全視角/TFT-H013A2QQIST3N10
  • Model : 1.3''TFT square/240*240 Resolution/TFTTFT-H013A2QQIST3N10

    Product type:TFT Strip

    Show contents:240x240

    Outline size(mm) :26.00×29.15×1.95

    Size of View Window(mm):1.3

    Display size(mm) :1.3

    Effective size(mm):23.4x23.4

    Product application:Instrumentation

    Visual angle:Full view

    Backlight type or brightness:350cd/m2

    Connection PIN Number:FPC-10PIN

    Interface mode:SPI

    Working temperature:-20~70℃

    Power supply voltage:2.8V

    Driver chip model:ST7789H2

Product description

This 1.3-inch TFT color screen is very suitable for handheld infrared thermometer display (infrared thermometer display), supports SPI interface, and has the characteristics of square size, compact structure, high brightness, full viewing angle, and rich colors. The data is clear at a glance.1.3寸TFT-H013A2QQIST3N10英文.jpgimage.png
